22240CC/W33

	d	D	B	C	C₀	P_u				* - SKF 22240CC/W

	mm			kN		kN	r/min		kg	-

	200	310	82	1000	1530	137	-	480	22,6	23040-2CS5K/VT143 *
	200	310	109	1290	2120	186	1300	1900	31,0	24040 CC/W33 *
	200	310	109	1290	2120	186	1300	1900	30,5	24040 CCK30/W33 *
	200	340	112	1600	2360	204	1500	1900	43,0	23140 CC/W33 *
	200	340	112	1600	2360	204	1500	1900	41,5	23140 CCK/W33 *
	200	340	112	1800	2800	232	-	320	53,5	23140-2CS5/VT143 *
	200	340	140	1800	2800	232	-	320	53,5	23140-2CS5K/VT143 *
	200	340	140	1800	2800	232	1100	1500	53,5	24140 CC/W33 *
	200	340	140	1800	2800	232	1100	1500	52,5	24140 CCK30/W33 *
	200	340	140	1800	2800	232	-	320	53,5	24140-2CS5/VT143 *
	200	360	98	1460	1930	166	1600	2200	43,5	22240 CC/W33 *
	200	360	98	1460	1930	166	1600	2200	42,5	22240 CCK/W33 *
	200	360	98	1460	1930	166	-	430	43,5	22240-2CS5/VT143 *
	200	360	98	1460	1930	166	-	430	42,5	22240-2CS5K/VT143 *
	200	360	128	1860	2700	228	1200	1700	58,0	23240 CC/W33 *
	200	360	128	1860	2700	228	1200	1700	56,5	23240 CCK/W33 *
	200	360	128	1860	2700	228	-	430	58,0	23240-2CS2/VT143 *
	200	360	128	1860	2700	228	-	430	58,0	23240-2CS5/VT143 *
	200	360	128	1860	2700	228	-	340	56,5	23240-2CS5K/VT143 *
	200	420	138	2320	2900	224	1200	1500	95,0	22340 CC/W33 *
	200	420	138	2320	2900	224	1200	1500	95,0	22340 CCJA/W33VA405 *
	200	420	138	2320	2900	224	1200	1500	95,0	22340 CCJA/W33VA406 *
	200	420	138	2320	2900	224	1200	1500	93,0	22340 CCK/W33 *
	200	420	138	2320	2900	224	1200	1500	93,0	22340 CCKJA/W33VA405 *
	220	300	60	546	1080	93	1900	2200	12,5	23944 CC/W33

start

prev 25

13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33

next 25

end

prev

next

	d	D	B	C	C₀	P_u				* - SKF 22240CC/W33

	mm			kN		kN	r/min		kg	-

	200	360	98	1460	1930	166	1600	2200	43,5	22240 CC/W33 *
